A reducer is an independent closed transmission device between the prime mover and the working machine, used to reduce speed and increase torque to meet work needs. In some cases, it is also used to increase speed, called a speed reducer. When selecting a reducer, it is necessary to compare the external dimensions, transmission efficiency, load-bearing capacity, quality, price, etc. of different types and varieties of reducers based on the selection conditions, technical parameters, performance of the power machine, economy, and other factors of the working machine, and choose the suitable reducer. A reducer is a relatively precise mechanical device used to reduce speed and increase torque.

1. The gears are made of high-strength low-carbon alloy steel through carburizing and quenching, with a tooth surface hardness of HRC58-62. The gears are all machined using CNC grinding technology, with high precision and good contact. 2. High transmission rate: single-stage greater than 96.5%, two-stage greater than 93%, three-stage greater than 90%. 3. Smooth operation and low noise. 4. Small size, light weight, long service life, and high load-bearing capacity. 5. Easy to disassemble and inspect, easy to install

A ring gear (A) is tightly connected to the gearbox housing, with a sun gear (B) driven by external power at the center of the ring teeth. Between the two, there is a set of planetary gear sets (C) consisting of three gears evenly divided and combined on a tray. The set of planetary gears relies on the output shaft, inner ring gear, and sun gear support to float during this period; When the input side power drives the sun gear, the planetary gearbox can drive the planetary gear to rotate and follow the trajectory of the inner ring gear to revolve around the center. The rotation of the planetary gear drives the output shaft connected to the tray to output power.

In the huge system of modern electrical equipment, single-phase AC motor is an extremely critical basic component, and its presence is everywhere in all areas of life and production. Whether it is home appliances that create a comfortable home environment or various types of machinery that promote efficient operation of industrial production, they are inseparable from the power support of single-phase AC motors. In-depth exploration of single-phase AC motors requires multiple dimensions such as its material composition, manufacturing process, application scenarios, and significant advantages, in order to fully understand its characteristics and value. ​ 1. Material composition: laying the foundation for performance (I) Core material As the core carrier of the magnetic circuit of a single-phase AC motor, the material performance of the core plays a decisive role in the operating efficiency and electromagnetic characteristics of the motor. Silicon steel sheets have become the preferred material for the core due to their low hysteresis loss and high magnetic permeability. During the operation of the motor, the magnetic field is in a state of continuous alternation. The low hysteresis loss of silicon steel sheets can effectively reduce the energy loss caused by repeated reversal of magnetic domains, making the motor more efficient in the energy conversion process. Its high magnetic permeability property helps to improve the conduction efficiency of the magnetic field, so that the magnetic field can be more concentrated to form a closed loop in the iron core, enhance the electromagnetic induction intensity of the motor, and thus improve the output power and torque performance of the motor. ​From the perspective of microstructure, the grain orientation of silicon steel sheets has a significant effect on their magnetic properties. Non-oriented silicon steel sheets are suitable for occasions where the direction of the magnetic field changes frequently. Their grains are randomly distributed and can conduct magnetic fields equally in all directions; while oriented silicon steel sheets are processed by special processes to arrange the grains in a specific direction. They have extremely high magnetic permeability in this direction and are often used in specific motor products with high requirements for magnetic properties. In terms of manufacturing process, the thickness of silicon steel sheets has also been carefully designed. Thinner silicon steel sheets can effectively suppress the generation of eddy currents and further reduce energy loss, but it will increase the cost and process difficulty of core manufacturing. ​(II) Winding material ​The winding is a key component for single-phase AC motors to achieve the conversion of electrical energy and magnetic energy. The choice of its material is directly related to the electrical performance, cost and service life of the motor. In practical applications, copper and aluminum are the most common winding materials. Each has its own advantages and disadvantages and is suitable for different application scenarios. ​Copper has excellent electrical conductivity and low resistivity. It can effectively reduce the resistance loss generated when current passes through the winding and reduce the heating of the motor during operation, thereby ensuring the stability and reliability of the motor during long-term operation. At the same time, copper has high mechanical strength and can withstand large tension during the winding process. It is not easy to break, which ensures the smooth progress of the winding manufacturing process. However, the price of copper is relatively high, which makes the motor with copper winding not cost-effective and limits its application in some cost-sensitive fields. ​The advantage of aluminum is its lower cost and lighter weight, which makes aluminum winding motors highly competitive in terms of price and can meet the needs of some occasions with strict requirements on equipment weight. However, aluminum is not as conductive as copper and has a higher resistivity. Under the same current and winding specifications, aluminum windings generate greater resistance losses, resulting in lower motor operating efficiency. In addition, the mechanical strength of aluminum is relatively weak, and it is more likely to deform and break during winding and use, which requires additional measures in process and design to solve. ​(III) Rotor material​As the rotating part of a single-phase AC motor, the rotor needs to have good electrical conductivity and mechanical strength to achieve efficient electromagnetic induction and stable rotational motion. Cast aluminum rotors are widely used in single-phase AC motors because of their simple process, low cost and ability to meet the performance requirements of most conventional application scenarios. Through the die-casting process, liquid aluminum is quickly injected into the mold to form a rotor with a specific shape and structure. The good electrical conductivity of aluminum can meet the rotor's need for induction current in a rotating magnetic field, and its low density makes the rotor's moment of inertia small, so that the motor can quickly respond to external control signals and achieve rapid start-up and speed regulation. ​For some special applications with high performance requirements, such as motors running at high speed and under high load conditions, copper alloy rotors are more advantageous. Copper alloys have higher electrical conductivity and mechanical strength, and can maintain stable performance under high speed and high torque working conditions, effectively reducing rotor heating and wear, and extending the service life of the motor. Common copper alloy rotor manufacturing processes include forging and precision machining, through which the dimensional accuracy and surface quality of the rotor can be accurately controlled to meet the strict requirements of high-performance motors. ​(IV) Other materials​The motor housing plays an important role in protecting internal components, supporting structures and heat dissipation in the motor. The selection of its material needs to comprehensively consider multiple factors such as strength, weight, heat dissipation performance and cost. The cast iron housing has high strength and good shock absorption performance. It can effectively resist external impact and vibration, protect the precision components inside the motor, and reduce the noise generated when the motor is running. It is suitable for large industrial motors with high requirements for stability and reliability. Aluminum alloy housings are widely used in some occasions with strict restrictions on equipment weight, such as portable devices and small motors in the aerospace field, due to their light weight and good heat dissipation performance. In addition, plastic housings are often used in motors in some small household appliances due to their low cost, good insulation performance and easy molding. ​As a key component supporting the rotation of the rotor, the material and performance of the bearing directly affect the running accuracy, stability and service life of the motor. High-quality bearing steel has high hardness, high wear resistance and good toughness. It can withstand the high-speed rotation and large load of the rotor, effectively reduce friction resistance and wear, and ensure the long-term stable operation of the motor. Insulating materials play a vital role in insulation isolation inside the motor, preventing short circuits between components with different potentials and ensuring the safe operation of the motor. Common insulating materials include polyester film, mica, epoxy resin, etc. These materials have good electrical insulation, heat resistance and mechanical properties, and can provide reliable insulation protection in the complex operating environment of the motor. ​ 2. Manufacturing process: Carving quality details​ (I) Iron core manufacturing process​The first link in iron core manufacturing is the punching of silicon steel sheets. Using high-precision punching equipment and molds, the silicon steel sheets are processed into punching sheets with specific tooth groove shapes according to design requirements. During the punching process, it is necessary to strictly control the accuracy of the punching die and the punching process parameters, such as punching force, punching speed, etc., to ensure the dimensional accuracy and edge quality of the punching sheet. Deviations in dimensional accuracy will lead to uneven air gaps after the core is stacked, increase magnetic resistance, and reduce the magnetic properties of the motor; while poor edge quality will produce burrs, affecting the insulation performance and assembly accuracy of the core. ​After punching, the core is stacked. Through special tooling equipment, the punching sheets are accurately aligned and stacked in a certain order and direction. During the stacking process, appropriate pressure needs to be applied to make the punching sheets fit tightly and reduce the air gap, while ensuring the overall dimensional accuracy and verticality of the core. In order to further reduce the eddy current loss in the core, after the stacking is completed, a layer of insulating paint is usually applied to the surface of the core to form an insulating layer, which isolates adjacent silicon steel sheets from each other, blocks the eddy current path, and improves the magnetic properties of the core and the operating efficiency of the motor. ​(II) Winding process​Winding is a process with extremely high requirements for precision and process, and its quality directly affects the electrical performance and reliability of the motor. First, it is necessary to select the appropriate specification of wire according to the design parameters of the motor, such as rated power, rated voltage, speed, etc., and determine the number of turns, winding method and winding sequence of the winding. Common winding methods include concentric winding, cross winding and parallel winding. Concentric winding is simple to wind and has neat ends, which is suitable for small motors; cross winding can improve the magnetic field distribution and improve the performance of the motor, and is often used in high-power motors; parallel winding is suitable for motors with special structures and performance requirements. ​During the winding process, professional winding equipment is used to accurately control the tension and winding speed of the wire. Appropriate wire tension can ensure the compactness of the winding and avoid the problem of electrical performance degradation and mechanical stability caused by loose winding; and stable winding speed helps to improve winding efficiency and winding quality. After winding, the winding needs to be insulated, usually by dipping in insulating varnish and drying. By dipping in insulating varnish, the gaps inside the winding can be filled to form a solid insulating layer, which can enhance the electrical insulation performance and mechanical strength of the winding and improve the moisture, mildew and corrosion resistance of the motor. ​(III) Rotor manufacturing process​The manufacture of cast aluminum rotors mainly adopts die casting process. First, the aluminum ingot is heated and melted to a liquid state, and then the high-temperature aluminum liquid is quickly injected into the mold cavity through a die-casting machine. During the die-casting process, the temperature of the aluminum liquid, die-casting pressure, and die-casting speed and other process parameters need to be precisely controlled. If the temperature of the aluminum liquid is too high, it will cause severe oxidation of the aluminum liquid, resulting in defects such as pores and slag inclusions; if the temperature is too low, the fluidity of the aluminum liquid will deteriorate, making it difficult to fill the mold cavity, causing problems such as material shortage. Reasonable selection of die-casting pressure and speed can ensure that the aluminum liquid fills the mold evenly, avoids casting defects such as shrinkage and pores, and ensures the quality and performance of the rotor. After the aluminum casting is completed, the rotor needs to be machined, such as turning and milling, to meet the requirements of the motor assembly for the rotor size accuracy and surface quality. ​For copper alloy rotors, forging or machining is generally used. The forging process can improve the internal structure of the copper alloy, improve its mechanical properties, and make the rotor have better strength and toughness when subjected to high speed and heavy load. After forging, the copper alloy rotor blank needs to undergo precision machining, including turning, grinding, drilling and other processes, to accurately control the outer diameter, inner diameter, shaft hole size and surface roughness of the rotor, to ensure the good fit between the rotor and other parts of the motor, and to meet the operating requirements of high-performance motors. ​(IV) Motor assembly process​Motor assembly is the key link in combining various components into a complete motor, and its assembly quality directly affects the overall performance and reliability of the motor. First, accurately install the stator into the motor housing, and ensure the position accuracy and fixation firmness of the stator through locating pins, bolts and other connectors. The deviation of the stator installation position will cause uneven air gap of the motor, affecting the electromagnetic performance and operating stability of the motor. ​Then, install the rotor into the center hole of the stator. During the installation process, special attention should be paid to ensure that the air gap between the rotor and the stator is uniform. The size of the air gap is an important parameter affecting the performance of the motor. If the air gap is too large, it will increase the magnetic resistance and reduce the power factor and efficiency of the motor; if the air gap is too small, it will easily cause friction and collision between the rotor and the stator, damaging the motor components. After installing the rotor, install the end cover. The end cover needs to ensure good matching accuracy and sealing performance with the stator and rotor to prevent dust, moisture and other impurities from entering the motor and affecting the normal operation of the motor. ​Then, install bearings, fans and other components. The installation of the bearings must ensure the matching accuracy with the rotor shaft and the end cover bearing hole, and use appropriate installation methods and tools to avoid bearing damage. The installation of the fan must ensure its balance performance to prevent vibration and noise during motor operation due to fan imbalance. Finally, make electrical connections, correctly connect the windings to the power line, control line, etc., and conduct comprehensive debugging and testing, including insulation performance testing, no-load performance testing, load performance testing, etc. of the motor to ensure that the various performance indicators of the motor meet the design requirements. ​ 3. Wide range of uses: integration into life and production​ (I) Household appliances​In the field of household appliances, single-phase AC motors are widely used, providing great convenience for people's daily lives. In terms of refrigeration equipment, the compressors of refrigerators and air conditioners are driven by single-phase AC motors. The refrigerator compressor realizes the compression, condensation, expansion and evaporation cycle of the refrigerant through the operation of the motor, maintains the low temperature environment inside the refrigerator, and ensures the preservation and storage of food. The compressor of the air conditioner is responsible for compressing and transporting the refrigerant to adjust the indoor temperature; at the same time, the indoor and outdoor fans of the air conditioner are also driven by single-phase AC motors to send cold (hot) air into the room to realize air circulation and heat exchange. ​In cleaning equipment, the motor of the washing machine undertakes the important task of driving the washing tub and the dehydration tub to rotate. Through the forward and reverse rotation and different speed control of the motor, the washing, rinsing and dehydration functions of the clothes are realized. The motor of the vacuum cleaner generates strong suction through high-speed rotation, sucking dust and debris into the dust bag to realize the cleaning function. In addition, kitchen appliances such as range hoods, juicers, soy milk machines, etc., as well as personal care appliances such as hair dryers, electric shavers, etc., are inseparable from the power provided by single-phase AC motors, so that these devices can work normally and meet the various needs of people's daily life. ​(II) Industrial equipment field​In industrial production, single-phase AC motors also play an indispensable role. In small processing equipment, such as drilling machines, milling machines, grinders, etc., single-phase AC motors provide rotational power to drive tools or workpieces for cutting, grinding and other processing operations to realize the processing and manufacturing of parts. In industrial automation production lines, single-phase AC motors are used to drive conveyor belts, sorting devices, packaging machinery and other equipment to realize material transmission, sorting and packaging processes, and ensure the continuity and efficiency of the production process. ​In the chemical, pharmaceutical and other industries, single-phase AC motors are often used to drive small pump equipment, such as centrifugal pumps, gear pumps, etc., to realize the transportation, circulation and metering of liquids. In the textile industry, motors provide power for looms, sewing machines, spinning machines and other equipment to promote the smooth progress of all links in textile production. In the field of agricultural production, single-phase AC motors are widely used in agricultural machinery such as small water pumps, electric sprayers, grain threshers, etc., to improve the efficiency and automation of agricultural production and reduce the labor intensity of farmers. ​(III) Commercial equipment field​In commercial places, single-phase AC motors also play an important role. In supermarkets, shopping malls and other retail places, the compressors of refrigerated display cabinets and freezers are driven by single-phase AC motors to maintain a low temperature environment and ensure the freshness and quality of food and goods. The automatic door system is driven by the motor to open and close automatically, providing convenience for customers while improving the image and grade of commercial places. In the catering industry, commercial dishwashers, soybean milk machines, ovens and other equipment all need single-phase AC motors to provide power to achieve functions such as tableware washing and food processing, and improve the efficiency and quality of catering services. In office places, printers, copiers, shredders and other office equipment also rely on the support of single-phase AC motors to ensure the smooth progress of office work. ​ 4. Significant advantages: highlighting unique charm ​ (I) Simple structure ​Compared with three-phase AC motors, the structure of single-phase AC motors is simpler and clearer. It is mainly composed of basic components such as stators, rotors, windings, capacitors, etc., and does not require complex three-phase power input and three-phase winding structure. The simple structural design not only reduces the manufacturing cost of the motor, reduces the number and types of parts, but also reduces the probability of failure during the operation of the motor, and improves the reliability and stability of the motor. At the same time, due to its simple structure, the daily maintenance and repair of single-phase AC motors are also more convenient. No professional and complex equipment and technicians are required. Ordinary maintenance personnel can inspect and maintain them, which reduces the cost of use and maintenance. ​(II) Low cost ​The advantages of low cost of single-phase AC motors are mainly reflected in two aspects. On the one hand,On the one hand, it has a simple structure, a small number of parts, and a relatively easy manufacturing process, which reduces the material cost, processing cost and assembly cost in the production process. On the other hand, in some applications where performance requirements are not high, low-cost materials such as aluminum wire windings and ordinary cast iron housings can be used to further reduce the manufacturing cost of the motor. This cost advantage makes single-phase AC motors very competitive in market areas that are more sensitive to prices, such as small household appliances, low-end industrial equipment, and commercial equipment, and can meet the needs of the majority of users for low-cost power equipment. ​(III) Convenient starting​Single-phase AC motors have a variety of simple and effective starting methods, the most common of which include split-phase starting, capacitor starting and shaded-pole starting. Split-phase starting sets the main winding and the auxiliary winding in the stator winding, and connects a resistor or capacitor in series in the auxiliary winding to make the current in the two windings have a phase difference, thereby generating a rotating magnetic field and starting the motor. Capacitor starting is to connect a capacitor in series in the auxiliary winding, and use the phase shifting effect of the capacitor to make the main and auxiliary winding currents have a larger phase difference, generate a stronger starting torque, and is suitable for occasions that require a larger starting torque. The shaded pole starting method is to start the motor by setting a short-circuit copper ring on the stator pole and using the principle of electromagnetic induction to generate a rotating magnetic field. This starting method has a simple structure and low cost, but the starting torque is small, which is suitable for some small and lightly loaded motors. These starting methods are simple in principle, do not require complex starting equipment and control systems, can start the motor quickly and conveniently, and meet the requirements of motor starting performance in different application scenarios. ​(IV) Stable operation​Under normal operating conditions, the rotor of a single-phase AC motor can rotate smoothly under the action of a rotating magnetic field and output a stable torque. Its speed is relatively stable and can meet the operating requirements of many devices that do not require high speed stability. Through reasonable design and control, such as optimizing the magnetic circuit structure and winding parameters of the motor and adopting appropriate speed regulation methods, the stability of the motor speed can be further improved. At the same time, the vibration and noise generated by the single-phase AC motor during operation are small, which is mainly due to its simple structural design and reasonable component layout. The low vibration and noise levels make the single-phase AC motor suitable for noise-sensitive environments such as homes, offices, and commercial places, and will not interfere with people's lives and work.​(V) Flexible Applications​Single-phase AC motors have a wide power range, from micro motors of a few watts to medium-sized motors of several kilowatts, which can meet application scenarios with different power requirements. At the same time, their design and configuration are very flexible. According to the specific requirements of the actual application, the performance of the motor can be optimized and adjusted by adjusting the winding parameters, changing the number of poles of the motor, and adopting different speed regulation methods. In addition, single-phase AC motors can also be used in conjunction with various control devices, such as frequency converters, speed regulators, controllers, etc., to achieve motor start-stop control, speed control, forward and reverse control, and various complex operation control functions, so that they can adapt to different working conditions and application requirements, and the application range is very wide. ​Single-phase AC motors have become an indispensable and important part of modern electrical equipment due to their unique material composition, fine manufacturing process, wide application fields and significant advantages. With the continuous advancement and development of science and technology, single-phase AC motors will continue to improve and optimize in terms of material research and development, process innovation, performance improvement, etc., to better meet the increasingly diversified and complex market needs, play a greater role in more fields, and bring more convenience and benefits to people's lives and production.
